X Ray Baggage Scanner
Model: NXBS -120
Introduction
We Neotech Solutions Ltd is a sole agent an professional security scanner equipment manufacturer, specialized the development and research in the x-ray imagine tehnology, metal detection technology, explosive detection, liquid detection and relative security services.
Special features:
- Network interface: Capable of connecting to LAN, and support multi-terminal check for baggage at same time,
- Safety ray: Ray is transmitted under automatic control, avoiding the error,
- One-key shutdown control: Just rotate the key to shut down the machine; it is safety, easy and convenient
- Eagle eye: Capable of expediently observing the magnifying area
- Self-diagnosis function: Give message automatically if malfunction for prompt maintenance
Specification
eneral Specifications:
Tunnel Size.........................................500 (W) ×300 (H) mm
Wire Resolution..................................40AWG
Steel Penetration................................38mm
Conveyor Max Load............................150 kg
Leakage radiation.............................. <0.06µGy/h
Single inspection dosage.................... <1.01μGy
Conveyor Speed................................. 0.22m/s
Film Safety.......................................... For ISO 1600
X-RAY GENERATOR:
Orientation.......................................... Upward
Tube Current.......................................0.4-1.25mA(adjustable)
Anode Voltage.....................................80-160KV(adjustable)
Angle...................................................80°
Generator cooling/working periods..... Sealed oil bath with forced air/100％
OPERATING ENVIRONMENT
Storage Temperature......................... -20oC to 60oC
Operating Temperature...................... 0oC to 45oC
Relative Humidity.................................20 to 95% non-condensing
System Power..................................... 220 VAC (±10%) 50±3HZ
Power wastage................................... 1.0 KW (Max)
Noise...................................................55DB
Image Performance System:
- Magnifier: Partial magnifying function
- Brightening/dimming: Increase/Decrease brightness of image
- Image recurrence: Display the previous twenty images and process any one of them
- Image restoration: Restore image to initial status
- Image storage: Real-time store any image and process it in operation status
- Display: High-resolution 19 inch color LCD display
- Color quality: 24-Bit real colors based on materials
- Edge enhancement: Object contour edge is more distinct
- Super image enhancement: Image detail is more distinct
- High penetration display: Increase the contrast of bright area in image to make the area that is easy to penetrate appear more clearly
- Low penetration display: Increase the contrast of dark area in image to make the area that is difficult to penetrate appear more clearly.
